时效态Mg-10Gd-3Y-0.6Zr合金的拉伸断裂行为
Fracture behavior of aged Mg-10Gd-3Y-0.6Zr alloy under tension loading
-
摘要: 研究了时效显微组织对Mg-10Gd-3Y-0.6Zr合金断裂行为的影响.结果表明:473K低温时效时,析出相小而密,由晶界析出相(GBP)引发的微裂纹在晶界处产生并沿晶内的择优取向扩展;温度达到523K时,GBP长大,应力集中仅在某些大尺寸GBP处出现,并引发GBP与基体分离,而产生微孔,微孔的聚集与长大导致了合金的断裂.微裂纹沿着孪晶与基体的界面扩展,在断口形成平滑刻面,而GBP的存在会加剧这一趋势.时效温度升高后,孪晶与GBP数量减少,滑移变形加剧,导致平滑刻面数量减少.Abstract: The effect of aging microstructure on the fracture behavior of Mg-10Gd-3Y-0.6Zr alloy was investigated.The results show that precipitates in the alloy after low temperature aging at 473 K are finer and denser.Microcracks nucleate at grain boundaries due to grain boundary precipitations (GBPs),and then propagate transgranularly along the preferred orientation.When the aging temperature increases to 523 K,the size of GBPs enlarges.Microvoids nucleate by interface debonding between GBPs and the matrix which is caused by stress concentration at large GBPs;subsequently,their coalescence and growth result in final fracture.Otherwise,smoothing facets on the fracture surface form by microcracks propagating along the interfaces between twins and the matrix,and this tendency is intensified due to the existence of GBPs.When the aging temperature increases,the smoothing facets reduce as the twins and GBPs decrease and the slip deformation intensifies.
