含固相铜冶炼渣的黏度计算及其应用

盛力; 李江涛; 张建坤; 张家靓; 张立峰; 侯新梅

doi:10.13374/j.issn2095-9389.2017.01.006

含固相铜冶炼渣的黏度计算及其应用

盛力¹,
李江涛^1,2,
张建坤^1,2,
张家靓^1,3, ,,
张立峰^1,3,
侯新梅¹

1) 北京科技大学冶金与生态工程学院, 北京 100083
2) 谦比希铜冶炼有限公司, 谦比希 999134, 赞比亚
3) 稀贵金属绿色回收与提取北京市重点实验室, 北京 100083

基金项目:

中央高校基本科研业务费资助项目（FRF-TP-15-068A1）

详细信息

分类号: TF811
计量
- 文章访问数: 1083
- HTML全文浏览量: 317
- PDF下载量: 57
出版历程
- 收稿日期: 2016-07-04
- 刊出日期: 2017-01-24

Viscosity calculation and its application of the copper smelting slag containing solid phase

1) School of Metallurgical and Ecological Engineering, University of Science and Technology Beijing, Beijing 100083, China
2) Chambishi Copper Smelter Limited, Chambishi 999134, Zambia
3) Beijing Key Laboratory of Green Recycling and Extraction of Metals, Beijing 100083, China

摘要

摘要: 利用Roscoe方程，结合FactSage的多元多相平衡计算和纯液相渣黏度计算功能可对含固相熔渣的黏度进行计算.本研究针对基于铜冶炼渣的FeO-SiO₂-Fe₃O₄-CaO-Al₂O₃-MgO系，首先根据相似炉渣的黏度测定值对Roscoe方程中的参数进行拟合，同时验证了该方法在计算所研究体系时的准确性.基于所得的计算模型考察不同组分含量对平衡相组成及黏度的影响规律，并总结获得合理的渣型配比.当炉渣中各组分的质量分数分别控制在FeO 40%~60%、SiO₂ 25%~40%、Fe₃O₄ 0%~15%、CaO 0%~10%、Al₂O₃ 0%~8%和MgO 0%~4%时，可在冶炼过程中得到流动性较好、固体量较少的熔渣.
- 铜冶炼 /
- 渣 /
- 黏度 /
- 固相 /
- 计算
Abstract: The viscosity of solid-containing slags can be calculated using the Roscoe equation combined with the calculation functions of multi-component & multi-phase equilibria and pure-liquid slag's viscosity in FactSage software. An FeO-SiO₂-Fe₃O₄-CaO-Al₂O₃-MgO system used in copper smelting was studied in this paper. Firstly, the parameters of the Roscoe equation were fitted using the measured viscosities of analogous slag in the literature, and the accuracy of viscosity calculated by the method for this slag system was verified additionally. Then, the effect of slag components' contents on the equilibrium phase-composition and viscosity was investigated based on the calculation model. Accordingly, the reasonable proportions of components in the slag were obtained. When the mass fractions of slag components are FeO 40%~60%, SiO₂ 25%~40%, Fe₃O₄ 0%~15%, CaO 0%~10%, Al₂O₃ 0%~8%, and MgO 0%~4%, the molten slag with good liquidity and fewer solids can be obtained in the smelting process.
- copper smelting /
- slag /
- viscosity /
- solid phase /
- calculations

HTML全文

参考文献(20)

[3]	Shiraishi Y, Ikeda Y, Tamura A, et al. On the viscosity and density of the molten FeO-SiO₂ system. Trans Jpn Inst Met, 1978, 19(5):264
[4]	Chen M, Raghunath S, Zhao B J. Viscosity measurements of "FeO"-SiO₂ slag in equilibrium with metallic Fe. Metall Mater Trans B, 2013, 44(3):506
[5]	Kucharski M, Stubina N M, Toguri J M. Viscosity measurements of molten Fe-O-SiO₂, Fe-O-CaO-SiO₂, and Fe-O-MgO-SiO₂ slags. Can Metall Q, 1989, 28(1):7
[6]	Ji F Z, Du S C, Seetharaman S. Experimental studies of the viscosities in the CaO-Fe_n O-SiO₂ slags. Metall Mater Trans B, 1997, 28(5):827
[7]	Chen M, Raghunath S, Zhao B J. Viscosity of SiO₂-"FeO"-Al₂O₃ system in equilibrium with metallic Fe. Metall Mater Trans B, 2013, 44(4):820
[8]	Seok S H, Jung S M, Lee Y S, et al. Viscosity of highly basic slags. ISIJ Int, 2007, 47(8):1090
[9]	Jeffrey D J, Acrivos A. The rheological properties of suspensions of rigid particles. AIChE J, 1976, 22(3):417
[10]	Roscoe R. The viscosity of suspensions of rigid spheres. Br J Appl Phys, 1952, 3(8):267
[11]	Wright S, Zhang L, Sun S Y, et al. Viscosities of calcium ferrite slags and calcium alumino-silicate slags containing spinel particles. J Non Cryst Solids, 2001, 282(1):15
[12]	Wright S, Zhang L, Sun S Y, et al. Viscosity of a CaO-MgO-Al₂O₃-SiO₂ melt containing spinel particles at 1646K. Metall Mater Trans B, 2000, 31(1):97
[13]	Kondratiev A, Jak E. Modeling of viscosities of the partly crystallized slags in the Al₂O₃-CaO-"FeO" SiO₂ system. Metall Mater Trans B, 2001, 32(6):1027
[14]	Kondratiev A, Jak E. Predicting coal ash slag flow characteristics (viscosity model for the Al₂O₃-CaO-‘FeO’-SiO₂ system). Fuel, 2001, 80(14):1989
[15]	Bale C W, Chartrand P, Degterov S A, et al. FactSage thermochemical software and databases. Calphad, 2002, 26(2):189
[17]	Keene B J, Mills K C. Densities of Molten Slags (Chapter 8), Slag Atlas. Dusseldorf:Verlag Stahl-Eisen, 1995
[18]	Pelton A D, Chartrand P. The modified quasi-chemical model:Part Ⅱ. Multicomponent solutions. Metall Mater Trans A, 2001, 32(6):1355
[19]	Seetharaman S, Mukai K,Du S C. Viscosities of slags:an overview//VⅡ International Conference on Molten Slags Fluxes and Salts. The South African Institute of Mining and Metallurgy, 2004
[20]	Seki K, Oeters F. Viscosity measurements on liquid slags in the system CaO-FeO-Fe₂O₃-SiO₂. Trans Iron Steel Inst Jpn, 1984, 24(6):445
[21]	Zhang H W, Sun F, Shi X Y, et al. The viscous and conductivity behavior of melts containing iron oxide in the FeOt-SiO₂-CaO-Cu₂O system for copper smelting slags. Metall Mater Trans B, 2012, 43(5):1046
[23]	Mackey P J. The physical chemistry of copper smelting slags:a review. Can Metall Q, 1982, 21(3):221
[24]	Higgins R, Jones T J B. Viscosity characteristics of Rhodesian copper smelting slags. Bull Inst Min Metall, 1963, 72:825
