Form of phosphate enrichment of the CaO base containing V2O5 and TiO2 semi-steel slag
-
摘要: 以Ca O基含V2O5、Ti O2脱磷终渣为研究对象, 采用共存理论建立磷富集程度Rci-cj模型, 并与实际渣系的磷酸盐赋存形式进行对比研究.结果表明:随着碱度的增加, 3CaO·P2O5的质量作用浓度逐渐降低, 4CaO·P2O5的质量作用浓度逐渐增加, 而2CaO·Si O2的质量作用浓度呈现出先增加后降低的趋势;C3P+C4P的富集可能性范围87%94%, C2S既是主要的硅酸钙化合物也是形成富磷产物必不可少的物质, 磷酸盐富集相中主要以C2S-C3P和C2S-C4P的形式存在于炉渣中, 结合扫描电镜 (SEM) 结果、X射线衍射 (XRD) 分析与假设, 计算可得深灰色富磷区域内的含P2O5固溶体为2CaO·Si O2-3CaO·P2O5和2CaO·Si O2-4CaO·P2O5, 此结果与理论计算相吻合.Abstract: Studying on the Ca O base containing V2O5and Ti O2semi-steel slag, a model of enrichment degree Rci-cjwas built with the help of the ion and molecule coexistence theory, the result was compared with the actual enrichment form of phosphate.The results indicate that with the increasing of basicity, the mass action concentration of 3CaO·P2O5gradually decreases, and the mass action concentration of 4CaO·P2O5gradually increases.While the mass action concentration of 2CaO·Si O2first increases and then decreases.The enrichment possibility range of the C3P+C4P is 87%-94%and the C2S that is the essential substance for the formation of the rich phosphate mineral phase is main calcium silicate compounds.The solid solution 2CaO-Si O2-3CaO-P2O5 (C2S-C3P) and 2CaO-Si O2-4CaO-P2O5 (C2S-C4P) are the primary phosphate enrichment phase in the slag.According to the scanning electron microscopy (SEM) results, X-ray diffraction (XRD) analysis and hypothesis, the containing P2O5solid solution in dark grey area is calculated as2CaO·Si O2-3CaO·P2O5and 2CaO·Si O2-4CaO·P2O5, which is consistent with the theoretical calculation results.
-
-
[1] Li J Y. Selective Enrichment and Phase Separation of Phosphate in Steelmaking Slags[Dissertation]. Beijing:University of Science and Technology Beijing, 2017 (李晋岩.钢渣中磷酸盐的选择性富集与分离[学位论文].北京:北京科技大学, 2017) [2] Guo H J. The Tutorials of Physical Chemistry of Metallurgy. 2nd Ed. Beijing:Metallurgical Industry Press, 2006 (郭汉杰.冶金物理化学教程. 2版.北京:冶金工业出版社, 2006) [3] Zhang J. Computational Thermodynamics of Metallurgical Melts and Solutions. Beijing:Metallurgical Industry Press, 2007 (张鉴.冶金熔体和溶液的计算热力学.北京:冶金工业出版社, 2007) [4] German Association of Iron and Steel Engineers. Slags Atlas.Wang J, translated. Beijing:Metallurgical Industry Press, 2007 (德国钢铁工程师协会编.渣图集.王俭, 译.北京:冶金工业出版社, 1989) [5] Verein Descher Eisenhuttenlente. Slag Atlas. 2nd Ed. Abington:Woodhead Publishing Limited, 1995
[6] Turkdogan E T. Physical Chemistry of High Temperature Technology. New York:Academic Press, 1980
[7] Chen J X. Chart Date in Steelmaking. 2nd Ed. Beijing:Metallurgical Industry Press, 2010 (陈家样.炼钢常用图表数据手册. 2版.北京:冶金工业出版社, 2010) [8] Liang Y J, Che Y C. Datasheet of Inorganic Thermodynamics. Shenyang:Northeast University Press, 1993) (梁英教, 车荫昌.无机物热力学数据手册.沈阳:东北大学出版社, 1993) [9] Hou G H, Li W F, Guo W, et al. Microstructure and mineral phase of converter. J Chin Ceram Soc, 2008, 36 (4) :436 (侯贵华, 李伟峰, 郭伟, 等.转炉钢渣的显微形貌及矿物相.硅酸盐学报, 2008, 36 (4) :436) [10] Yang X M, Duan J P, Shi C B, et al. A thermodynamic model of phosphorus distribution ratio between CaO--SiO2-Mg O-Fe O--Fe2O3--Mn O-Al2O3--P2O5slag and model steel during top-bottom combined blown converter steelmaking process based on the ion and molecule coexistence theory. Metal Mater Trans B, 2011, 42B (4) :738
[11] Ban-ya S, Hino M, Stao A, et al. O, P and S distribution equilibria between liquid iron and CaO-Al2O3-FetO slag saturated with CaO. Tetsu-to-Hagane, 1991, 77 (5) :361
[12] Young R W, Duffy J A, Hassall G J, et al. Use of the optical basicity concept for determining phosphorus and sulphur slag/metal partitions. Ironmaking steelmaking, 1992, 19 (3) :201
[13] Ito K, Yanagisawa M, Sano N. Phosphorus distribution between solid 2CaO·SiO2and molten CaO--SiO2--Fe O-Fe2O3slag. Tetsuto-Hagane, 1982, 68 (2) :342
[14] Diouri A, Boukhari A, Aride J, et al. Stable Ca3SiO5solid solution containing manganese and phosphorus. Cement Concrete Res, 1997, 27 (8) :1203
[15] Zhang Y Z, Bao J W, Long Y, et al. Law of isothermal crystallization kinetic of C2S in gas quenching slag affected by CaO. Iron Steel, 2013, 48 (11) :84 (张玉柱, 鲍继伟, 龙跃, 等. CaO对气淬钢渣中C2S等温析晶动力学影响规律.钢铁, 2013, 48 (11) :84) [16] Lin L, Bao Y P, Wang M, et al. Influence of titanium modification on phosphorus enrichment in P-bearing steel-making slag. J Univ Sci Technol Beijing, 2014, 36 (8) :1013 (林路, 包艳平, 王敏, 等.二氧化钛改质对含磷转炉渣中磷富集行为的影响.北京科技大学学报, 2014, 36 (8) :1013) [17] Li J Y, Zhang M, Guo M, et al. The comprehensive effect of binary and Al2O3on phosphate enrichment mechanism in steelmaking slag. Chin J Eng, 2016, 38 (5) :668 (李晋岩, 张梅, 郭敏, 等. Al2O3和二元碱度对炼钢炉渣中磷酸盐富集机理的综合影响.工程科学学报, 2016, 38 (5) :668) [18] Matsubae-yokoyama K, Kubo H, Nagasaka T. Recycling effects of residual slag after magnetic separation for phosphorus recovery from hot metal dephosphorization slag. ISIJ Int, 2010, 50 (1) :65
